Procedure Making & Interpretation of Data as per Procedure or Clients requirements.
PROCEDURE NEED FOR TOFD as  perticular job requirements.

1. Chapter 1 – TOFD Introduction & History
2. Chapter 2 – TOFD Vs Other methods
 TOFD Signals Signals received
      • Lateral wave (LW), subsurface
      • Back-wall echo(BW)
      • Mode converted ( shear wave echo)
      • Diffracted signals from defects

3. Chapter 3 – Physics – Tip Diffraction
Diffraction Mechanism, Effects of Diffraction, Ultrasonic diffraction
4. Chapter 4 – Fundamentals of TOFD
Basic Setup, TOFD Signals, The Lateral wave, Back wall Signal, Diffracted wave - Defect signals,
     Mode converted shear signals, Phase - Relationship between waves, ToFD Data Visualization
     (A-Scan to B-Scan), TOFD Dead Zones, ToFD Probe angle, Transducer size, Probe frequency
      TYPICAL TOFD SETUP, Time of Arrival calculation

5. Chapter 5 – Equipment Setup & Parameters Selection
Probe, Beam spread, Difference in beam spread with respect to frequency, Probe frequency, Probe angle,
     Recommended Probe selection parameters for thickness up to 70mm, Probe-Centre Separation (PCS),
     Probe-Centre Separation
     Settings Gain setting, Time window settings, Time-to-depth conversion (Screen Calibration),
      Sensitivity settings, Calibration,
      Scanning : Longitudinal scan - Non-Parallel or D-scan or line scan, Limitations
                         Parallel scan - Lateral, transverse or B-scan, Limitation
                         Mechanical Scanner
                         Scan Resolution (Sampling Interval), Parameters for a ToFD Scan

                         Parameters to be considered in TOFD
                         Transducer size & Probe frequency

6. Chapter 6 - Errors in TOFD
Errors in the timing
                         Near Surface errors
                         Dead zone errors
                         Resolutions of top and bottom tips
                         Off-Axis depth error
                          PCS errors Multiple arcs
                          Other errors

7. Chapter 7 – Digitization Principles
Key Parameters of digitizer
                         • Frequency (Digitizer)
                         • Processor (no. of bits or amount of information that can be handled)
                         • Averaging
                         • PRF
                         • Acquisition Rate
                         • Soft Gain

8. Chapter 8 – Data Analysis & Sizing
Interpretation and analysis of TOFD images
                         Assessing the quality of the TOFD image
                         Identification of relevant indications
                         Classification of relevant indications
                         Surface breaking discontinuities
                         Embedded discontinuity indications
                         Gain Settings, Missed Scan, Loss of Signa, Effect of thick couplant layer,
                         Screen Calibration , Lateral wave synchronization, Sizing Techniques,
                         Height measurements, Synthetic Aperture Focusing Technique (SAFT) ,
                         TOFD image of surface notch's,
TOFD image of opposite surface discontinuity,
                          TOFD image of opposite surface discontinuity with a larger depth,
                          TOFD image of a through wall discontinuity, TOFD image of point like discontinuities,
                          TOFD image of a change in thickness

9. Chapter 9 – Codes & Standards - TOFD
Many national and International standards or European Standards are available :-
                         EN, ASME, ASTM, AWS, ISO, etc.

10.Chapter 10 – Applications of TOFD

TOFD of Welds Images
